| General |
|
Product Type
|
Smartphone |
|
Manufacturer Model Number
|
SM-F707U |
|
Form Factor
|
Folder (flip) - touch screen, dual screen |
|
Protection
|
Water-resistant |
|
Width
|
2.9 in |
|
Depth
|
0.3 in |
|
Height
|
6.6 in |
|
Weight
|
6.45 oz |
|
Dimensions Details
|
Unfolded - 2.9 in x 0.3 in x 6.6 in Folded - 2.9 in x 0.6 in x 3.4 in |
|
Body Color
|
Mystic gray |
|
SAR Value
|
1.59 W/kg (simultaneous), 1.35 W/kg (wireless router), 0.9 W/kg (body), 0.7 W/kg (head) |
| Cellular |
|
Technology
|
CDMA2000 1X / GSM / WCDMA (UMTS) |
|
Mobile Broadband Generation
|
5G |
|
Service Provider
|
T-Mobile |
|
Operating System
|
Android 10 |
|
Intelligent Assistant
|
Bixby |
|
Navigation
|
GPS, GLONASS, BeiDou, Galileo |
|
SIM Card Type
|
Nano SIM, Electronic SIM card (e-SIM) |
|
SIM Card Qty
|
Dual-SIM |
|
Payment Technology
|
Samsung Pay |
|
Input Device
|
Multi-touch |
| Messaging & Internet |
|
Messaging Services
|
SMS, MMS |
| Communications |
|
Data Transmission
|
GPRS, EDGE, EV-DO, HSDPA, HSUPA, HSPA+, FDD-LTE, TDD-LTE, 5G NR FR1 |
|
2G Band
|
850 GSM, 900 GSM, 1800 GSM, 1900 GSM, 800 CDMA2000 1X, 1900 CDMA2000 1X |
|
3G UMTS Band
|
Band 1, Band 2, Band 4, Band 5, Band 8 |
|
3G UMTS Frequency
|
2100, 1900, 1700, 850, 900 |
|
4G LTE Band
|
Band 1, Band 2, Band 3, Band 4, Band 5, Band 7, Band 8, Band 12, Band 13, Band 14, Band 20, Band 25, Band 26, Band 28, Band 38, Band 39, Band 40, Band 41, Band 48, Band 66, Band 71 |
|
4G LTE Frequency
|
FDD 2100, FDD 1900 PCS, FDD 1800+, FDD 1700 - 2110 AWS, FDD 850, FDD 2600, FDD 900, FDD 700a, FDD 700c, FDD 700 PS, FDD 800 DD, FDD 1900+, FDD 850+, FDD 700 APT, TDD 2600, TDD 1900, TDD 2300, TDD 2500, TDD 3600, FDD 1700 - 2110 AWS-3, FDD 600 |
|
5G NR Band
|
N41, n71 |
|
5G NR Frequency
|
TDD TD 2500, FDD 600 |
|
Wireless Interface
|
NFC, IEEE 802.11a/b/g/n/ac, Bluetooth 5.0, IEEE 802.11a/b/g/n/ac/ax |
| Phone Features |
|
Phone Functions
|
Speakerphone, voice control, call timer, conference call, flight mode, voice dialing, vibrating alert |
|
Sensors
|
Accelerometer, proximity sensor, barometer, gyro sensor, hall sensor, RGB sensor, geomagnetic sensor |
|
Security Devices
|
Face recognition, fingerprint reader (side) |
|
Additional Features
|
Multitasking, MU-MIMO technology, Samsung KNOX, High AOP Mic, Smart View, Bixby Vision, Bixby Routines, Intelligent Performance Enhancer, Flex mode, Multi Active Window |
| Media Player |
|
Supported Digital Audio Standards
|
WAV, WMA, AAC, PCM, AMR, MP3, FLAC, XMF, OGG, MIDI, APE (Monkey's Audio), M4A, DSF, DSD, MXMF, OGA, 3GA, AWB, IMY, RTTTL, RTX, OTA, DFF, MID, DSD64, DSD128 |
|
Supported Digital Video Standards
|
MKV, FLV, AVI, MPEG-4, WMV, ASF, 3GP, M4V, WebM, 3G2 |
|
Sound Enhancements
|
Dolby Digital Plus sound, Dolby Digital sound |
| Processor |
|
Clock Speed
|
2.9 GHz |
|
Processor Core Qty
|
8-core |
|
64-bit Architecture
|
Yes |
| Memory |
|
RAM
|
8 GB |
|
Internal Memory Capacity
|
256 GB |
|
User Memory
|
221.5 GB |
| Front Camera |
|
Sensor Resolution
|
10 Megapixel |
|
Lens Aperture
|
F/2.4 |
|
Focus Adjustment
|
Automatic |
|
Field of View (FoV)
|
80 degrees |
|
Pixel Size
|
1.22 µm |
|
Camera Modes
|
Live Focus mode, Live focus video |
| Rear Camera |
|
Sensor Resolution
|
12 Megapixel |
|
Optical Image Stabilizer
|
Optical Image Stabilizer (OIS) |
|
Lens Type
|
Wide-angle lens |
|
Lens Aperture
|
F/1.8 |
|
Field of View (FoV)
|
78 degrees |
|
Pixel Size
|
1.4 µm |
|
Focus Adjustment
|
Automatic, manual |
|
Digital Zoom
|
8 |
|
Self-Timer Delay
|
Yes |
|
Special Effects
|
HDR, Grid Line |
|
Camera Modes
|
Slow motion video, Panorama, Pro mode, HYPERLAPSE, Live Focus mode, Super Slow-mo, AR Emoji, Flowers, Greenery, Trees, Sky, Mountains, Beaches, Watersides, Snow, Backlit, Text, Motion Photos, Food, Face, Baby, Person, Dog, Cat, People, Sunset, Sunrise, City, Waterfall, Scenery, Stage, Vehicles, Drinks, Animal, Shoes, Indoor, Clothes, Night view, Live focus video, Filter mode |
|
Light Source
|
High CRI LED flash |
|
Video Resolutions
|
1920 x 1080 (1080p) at 60 fps, 1280 x 720 (720p) at 30 fps, 3840 x 2160 (4K) at 60 fps, Slo-mo video 1920 x 1080 (1080p) at 240 fps, Slo-mo video 1280 x 720 (720p) at 960 fps |
|
Features
|
Quick Launch, Playback zoom, blink detection, VDIS (Video Digital Image Stabilization), Tracking AF, Video location tags, location tags, Hyperlapse video support 1080p, Scene Optimizer, Flaw detection, 9.1MP still photos recording 4K video, Shot suggestions, blur detection, HDR10+ recording, Floating shutter button, Super steady, Super Speed Dual Pixel AF, AR Doodle |
| Second Rear Camera |
|
Lens Type
|
Ultra wide-angle lens |
|
Lens Aperture
|
F/2.2 |
|
Field of View (FoV)
|
123 degrees |
| Display |
|
Type
|
OLED display |
|
Technology
|
Infinity Flex Dynamic AMOLED |
|
Diagonal Size
|
6.7" |
|
Display Resolution
|
2636 x 1080 pixels |
|
Display Format
|
Full HD+ |
|
Pixel Density
|
425 ppi |
|
Aspect Ratio
|
21.9:9 |
|
Protection
|
Samsung Ultra Thin Glass |
|
Features
|
Always-on display, Edge Screen, Edge Lighting, Video Wallpaper |
| Display (2nd) |
|
Color Depth
|
16.7 million colors |
|
Type
|
OLED display - color |
|
Diagonal Size
|
1.05" |
|
Display Resolution
|
300 x 112 pixels |
| Connections |
|
Connector Type
|
USB Type-C - 24 pin USB-C |
| Battery |
|
Capacity
|
3300 mAh |
|
Fast Charging Technology
|
Qualcomm Quick Charge 2.0, Adaptive Fast Charging |
|
Wireless Charging
|
Yes |
|
Wireless Charging Standards
|
WPC, Qi, Wireless PowerShare |
|
Talk Time
|
1440 minutes |
|
Run Time Details
|
Talk: up to 1440 min Active online usage (LTE): up to 13 hrs Active online usage (Wi-Fi): up to 13 hrs Playback (wireless audio): up to 63 hrs Playback (wireless video): up to 18 hrs |
| Miscellaneous |
|
Compliant Standards
|
VDE, SGS |
|
Included Accessories
|
Power adapter |
| Manufacturer Warranty |
|
Service & Support
|
Limited warranty - 1 year |
| Universal Product Identifiers |
|
Brand
|
Samsung |
|
Part Numbers
|
SM-F707U, SM-F707UZAATMB, sm-f707uzaatmb |
|
GTIN
|
00887276451695 |
